Tilting Arbour Circular Saw Machine

Name: Tilting Arbour Circular Saw Machine
Brand: NORTON ENGG WORKS
Price: 32000.00 INR
Availability: InStock

Price 32000.00 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Tilting Arbour Circular Saw Machine Specification

Product Type
Woodworking Machine

Machine Type
Wood Planer

Machine Style
Horizontal

Capacity
Depends on blade and motor (typically 12-18 blade capacity)

Voltage
440 Volt (v)

Power
3 HP to 5 HP (Varies with model)

Automation
Semi Automatic

Motor
Heavy Duty Induction Motor

Speed
2800 RPM (Approximate)

Dimension (L*W*H)
Approx. 1200 mm x 900 mm x 950 mm

Weight
Approx. 350 kg

Color
Red and Black

Table Size
850 mm x 760 mm

Table Height from Ground
850 mm

Max Depth of Cut at 45
75 mm

Rip Fence
Heavy Duty Adjustable

Blade Tilt
0 to 45

Arbour Size
25.4 mm

Saw Blade Diameter
305 mm to 400 mm

Dust Collection Port
Provided

Max Depth of Cut at 90
100 mm

Application
Precise ripping, cross-cutting, bevel cutting in wood working shops and industries

Body Material
Cast Iron and Mild Steel Construction

Tilting Arbour Circular Saw Machine Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
10 Pieces Per Month

Delivery Time
15-20 Days

About Tilting Arbour Circular Saw Machine

Tilting Arbour Circular Saw Machine is a portable mechanical tool used in DIY jobs to cut large pieces of wood, metals, plastic, concrete and other materials like tiles and bricks. It can make curvilinear and straight cuts. Tilting Arbour Circular Saw Machine goes through varied quality checks before the final dispatch from our unit

Versatile Cutting Performance

This tilting arbour circular saw offers a tilting range of 0 to 45 degrees, accommodating both straight and beveled cuts with precision. The height adjustment hand wheel and customizable arbour diameter further enhance its flexibility for diverse woodworking tasks.

Heavy Duty Construction

Built with a robust mild steel body and powder-coated finish, this machine is engineered to withstand intensive use in commercial and industrial settings. Its heavy-duty induction motor and belt-driven system ensure steady operation and longevity.

Safety and Clean Workspace

Equipped with a blade guard and manual dust collection, the saw prioritizes operator safety and maintains a tidier environment. An optional dust port is available for advanced dust management, supporting cleaner, more efficient workshops.

FAQ's of Tilting Arbour Circular Saw Machine:

Q: How does the tilting arbour mechanism enhance cutting versatility?

A: The tilting arbour allows the saw blade to be angled from 0 to 45 degrees, enabling users to make bevel cuts in addition to standard straight cuts, making it suitable for various woodworking applications.

Q: What types of materials can be cut with this machine?

A: This saw is primarily designed for wood and engineered boards, making it suitable for cutting timber, plywood, chipboard, and other carpentry materials.

Q: When is blade height adjustment necessary, and how is it performed?

A: Blade height adjustment is needed when changing cutting depth for materials of varying thickness. The hand wheel mechanism allows users to raise or lower the blade smoothly to achieve the desired depth.

Q: Where should the Tilting Arbour Circular Saw Machine be installed?

A: The machine should be installed in a well-ventilated, level workspace with adequate electrical supply (440 Volt). A spacious area allows safe operation and easy management of large workpieces.

Q: What safety features are included with this saw?

A: It includes a sturdy blade guard to protect the operator from accidental contact with the blade. The adjustable rip fence adds to safe and accurate material guidance during cuts.

Q: How does the dust collection process work, and are additional options available?

A: Manual dust collection is standard, helping to remove sawdust and debris. For better dust control, an optional dust port can be added to connect with industrial vacuum systems.

Q: What are the main benefits of using this semi-automatic saw for carpentry work?

A: Key benefits include accurate angle/bevel cuts, sturdy construction for heavy-duty use, reliable performance with a powerful motor, and safety enhancements, all of which improve productivity and result quality in carpentry and woodworking tasks.
